The installation of hydropower in home renovation is a major project, and the installation cost of hydropower should not be overlooked. Only by strictly controlling the expenses for the installation of hydropower can we put the decoration costs where they are needed. Next, Xiaobian gave everyone a detailed introduction on how to save money by installing hydropower installation specifications and hydropower reforms.
Hydropower installation specification
1, the wiring principle: horizontal and vertical, the use of special PVC flame-retardant wire tube, wire tube must be fixed in the line slot, wire box and line pipe should be used when the lock mother, straight pipe every 80 cm using a tube card, Use a tube card every 20 centimeters around the corner.
2. In the upper part of the wall, the socket is vertically slotted upwards in the wall, and in the installation line of the decorative angle line at the top of the wall, if it is in the lower part of the wall, it shall be vertically slotted downwards to the bottom of the skirting board to be installed. Should be consistent, slot line and top straight line should be ejected after the control line in the wall, and then cut the wall surface with a cutting machine, slotted with a machine.
3, the use of PVC pipe, in the elbow when the spring is bent, do not use the 90-degree elbow and the tee, the line must be installed when the care line casing, using adhesive to connect, the casing edge should be close, straight, Smooth and right-angled corners should be cut in the inside of the corner. After cutting the arc-shaped interface on one side of the incision, bend and install.
4, moderate depth of pipe teeth, no burr. The pipe joints are wrapped with raw material and wrapped 5-6 turns. The number of pipe twisted teeth is 5 teeth-6 teeth until the joint is tightened, and rotten teeth are not allowed to enter the pipe.
5, after the wire is installed into the casing, the wire fixing tool should be used. After fixing the wire inside the wall and the wall, the plaster is concealed.
6. It is forbidden to lay the line pipe directly under the composite plate. The line pipe under the solid wood floor must be reinforced.
7. It is strictly forbidden to lay the line pipe on the kitchen or bathroom floor to prevent water from penetrating into the line pipe.
8. The wire that passes into the line pipe should not be more than 40% of the hole area of ​​the line pipe. There must be no joints in the pipe wires, and the wires of different purposes must not be mixed in one wire pipe.
9, the wire into the box must be guaranteed to leave a certain length, leaving 10 to 15 cm, wearing a hose to switch, socket installation and maintenance.
10. The distance from the wall to the water pipe should be 1.5cm, left and right cold, and 15cm apart.
11. The parallel distance between the wire and the water pipe should not be less than 30 cm, and the distance between the crossing and the bridge should not be less than 10 cm.
12. Wire points and points must not have joints, and the dark lines in the ceiling must have flame-retardant tube protection.
13. After the acceptance of water and electricity is passed, powder lined trough and wall trough can be filled and compacted with 1:3 cement mortar.
How to save money for hydropower reform
1, control drawings strict budget
In the signing of the renovation contract, the designer may be asked to present the hydropower reform drawings, and then the materials used in the telephone lines, power outlets, switch panels, network cables, etc. shall be strictly calculated according to the drawings, and then reasonable expenses shall be calculated to avoid excessive increase of the additional costs.
2, mid-term acceptance to avoid rework
In the middle period of hydropower reform, we also need to carry out some acceptance to avoid rework. For example, when the waterproofing of the kitchen and toilets and the buried underground hydropower pipelines are accepted, if the waterproofing of the tiles is found to be unqualified after the completion of the construction of the tiles, the electric lines are blocked, and the plumbing pipes are blocked or leaking, they can only be reworked.
The above is related to the hydropower installation specification and the related knowledge on how to save money for hydropower reform. After reading it, is there any more understanding of this aspect? If you want to know more relevant knowledge, please continue to pay attention to this site information, more exciting, so stay tuned!
